Parts |
 |
P/N, description, qty needed. |
from |
to |
GBP |
| 1 |
RLH101090 - Hub rear - LH
Except: Anti Lock Brakes
superceeded by
RLH101110
|
|
2D600100 |
|
| 1 |
RLH101110 - Hub rear - LH
|
|
2D600100 |
72,38 |
| 1 |
RLH101080- Hub rear - RH
Except: Anti Lock Brakes
superceeded by
RLH101100
|
|
2D600100 |
|
| 1 |
RLH101100 - Hub rear - RH
|
|
2D600100 |
72,38 |
| 2 |
RGU100231 - Bracket-anti-roll bar mounting
rear Suspension - LH
|
|
2D600100 |
2,57 |
| 2 |
RGU100221 - Bracket-anti-roll bar mounting
rear Suspension - RH
|
|
2D600100 |
2,57 |
| 3 |
FS110251 - Screw -
M10 x 25
|
|
2D600100 |
1,02 |
| 4/5 |
RFM000050 - Kit-hub bearing - front/rear
- QH QWB661
- Lockheed BK405
- Unipart GHK1366
|
|
|
46,23 |
| 6 |
EJP7738 - Nut-stake - R/H thread
|
|
|
1,36 |
| 7 |
NAM6530 - Flange assembly-drive
|
|
2D600100 |
66,38 |
| 8 |
FAM8419 - Stud
|
|
|
3,05 |
| 9 |
SDB100460 - Disc - solid brake - rear
240 x 10mm
(Min 9mm)
height 43mm Center d 65mm
EBC D849
MINTEX MDC1077
GBD90842
|
|
|
54,26 |
| 10 |
SF106161 - Screw
|
|
|
0,48 |
| 11 |
FN110041 - Nut -
M10
|
|
2D600100 |
0,71 |
|
|
|
 |
