Parts |
 |
P/N, description, qty needed. |
from |
to |
GBP |
| 1 |
ALA460130 - Body side assembly
- LH
|
2D600101 |
|
273,77 |
| 1 |
ALA460120 - Body side assembly
- RH
|
|
|
273,77 |
| 2 |
AME460410 - Closing assembly
-front sill outer - LH
|
|
|
15,26 |
| 2 |
AME460400 - Closing assembly
-front sill outer - RH
|
|
|
15,26 |
| 3 |
ALX460070 - Extension-outer sill front
- LH
|
|
|
23,89 |
| 3 |
ALX460060 - Extension-outer sill front
- RH
|
|
|
22,20 |
| 6 |
ALX460030 - Extension-drain channel
- LH
|
|
|
7,08 |
| 6 |
ALX460020 - Extension-drain channel
- RH
|
|
|
7,08 |
| 7 |
ALX460090 - Extension
-rear lamp aperture - LH
|
|
|
7,45 |
| 7 |
ALX460080 - Extension
-rear lamp aperture - RH
|
|
|
7,45 |
| 8 |
ALX460130 - Extension
-rear wheelarch - LH
|
|
|
5,98 |
| 8 |
ALX460120 - Extension
-rear wheelarch - RH
|
|
|
5,98 |
| 9 |
ALB460030 - A post assembly - LH
|
|
|
91,26 |
| 9 |
ALB460020 - A post assembly - RH
|
|
|
91,26 |
| 10 |
ALU460110 - Bracket-rear bumper
-support
|
|
|
2,62 |
| 11 |
ACG460010 - Header-body front
|
|
|
27,36 |
| 12 |
AAL460070 - Closing-front header
|
|
|
32,02 |
|
|
|
 |
