Parts |
 |
P/N, description,
qty needed. |
from VIN |
to VIN |
GBP
|
| 1 |
PEB102510 - Pump assembly
- engine coolant
- with evaporation chamber
- Teeth 24
earlier numbers and aftermarket p/n
- FALCON FWP308
- QH2743
- Sil PA 683
- Airtex-Lai 1398
- Airtex-Lai 1399
- Bendix 491362B
- Bendix 491363B
- Bugatti Autoricambi PA5202
- Bugatti Autoricambi PA5203
- Caterham GWP333
- Centro 986022767
- Coparts 01-41-141-0
- Delphi Lockheed WP1728
- Delphi Lockheed WP1729
- Dolz M142
- Dolz M143
- FAI WP2743
- Firstline FWP1492
- Firstline FWP1799
- GP PA668
- Graf PA426
- Graf PA427
- KWP 10426
- KWP 10427
- Land Rover PEB10051
- Lotus A111E6088S
- Motaquip VWP449
- Motaquip VWP450
- Reliant GWP336
- Rover Group GWP333
- Rover Group GWP336
- Saleri PA682P
- Saleri PA683P
- Sasic 9001004
- Sasic 9001010
- SKF VKPC87400
- SKF VKPC87401
- Spidan 0.060352
- Unipart GWP333
- Unipart GWP336
- Valeo 506018
- Valeo 506114
- Veco VF418
- Veco VF419
+ GWP333Z
|
|
|
49,81 |
| 2 |
PET10010 - O ring
superceeded by
PET10010B
|
|
|
1,13 |
| 3 |
WAM4059 - Dowel
2 of
|
|
|
0,38 |
| 4 |
FS106205E - Screw
-flanged head
4 of
|
|
|
0,31 |
| 5 |
PEW100070 - Bolt
- coolant pump support
- with evap chamber
|
|
|
2,93 |
| 6 |
PEM10025 - Housing assembly
-thermostat
|
|
2D600100 |
30,29 |
| 6 |
PEM101070 - Housing assembly-thermostat
superceeded by
PEM10025 |
|
|
28,03 |
| 7 |
PEL10016 - Thermostat-engine
with outer gasket ring
- 88 degrees C
(GTS301)
GTG219 Gasket
|
|
2D600100 |
9,49 |
| 8 |
PEF10010 - Seal
-thermostat housing
- FACET 7.9605
|
|
|
1,68 |
| 9 |
CDU3858 - O ring
2 of
|
|
|
0,38 |
| 10 |
FS106205 - Screw
-flanged head
- M6 x 20
|
2D600101 |
|
0,39 |
| 11 |
FB106081 - Bolt
- M6 x 40
|
|
|
0,50 |
| 12 |
PEQ100680 - Elbow
- engine coolant outlet
|
|
|
13,89 |
| 13 |
PET10042 - Gasket
- cylinder head coolant outlet
superceeded by
PET10042B |
|
|
0,87 |
| 14 |
FS106201 - Screw
- flanged head
- M6 x 20
FS106207 |
|
|
0,58 |
| 14 |
FS106207 - Screw
- flanged head
- M6 x 20 |
|
|
0,31 |
| 15 |
PEM000020 - Housing
- thermostat (PRT related)
|
2D600101 |
|
15,75 |
| 16 |
PEL000040A - Flange-water
pump outlet
(PRT related)
|
2D600101 |
|
1,41 |
|
|
 |
|
