P/N, description, qty needed.
|
from VIN |
to VIN |
GBP
|
| 1 |
MKC103730 - Electronic control unit
engine
superceeded by
MKC104110
MKC104111
MKC104112
MKC104112E |
|
AD009461 |
386,45 |
| 1 |
MKC104110 - Electronic control unit
engine
superceeded by
MKC104111
MKC104112
MKC104112E |
AD009462 |
AD 18809 |
417,98 |
| 1 |
MKC104111 - Electronic control unit
engine (except VVC)
superceeded by
MKC104112
MKC104112E |
AD 18810 |
WD029769 |
409,81 |
| 1 |
MKC104112 - Electronic control unit
engine
superceeded by MKC104112E
|
WD029770 |
YD522572 |
424,80 |
| 1 |
MKC104112E - Electronic control unit
engine - exchange
|
WD029770 |
YD522572 |
187,77 |
| 1 |
NNN100901 - Electronic control unit
engine
- Automatic / Stepspeed |
|
YD522572 |
409,64 |
| 1 |
NNN000060 - Electronic control unit
engine
Except: Anti Lock Brakes
|
|
|
233,51 |
| 1 |
NNN100783 - Electronic control unit
engine
Manual & Anti Lock Brakes
Automatic
|
YD522573 |
4D639328 |
233,51 |
| 1 |
NNN100743 - Electronic control unit
engine
also R45 and R25 120PS
|
4D639329 |
|
283,00 |
| 1 |
NNN000830 - Electronic control unit
engine
EU4 |
EU4
16K4FS01/02 or
18K4S03 to 18K4FS07 |
|
283,00 |
| 2 |
NNU100410- Bracket-mounting engine-electric
control unit
superceeded by NNU100780 |
|
XD507388 |
13,47 |
| 2 |
NNU100780 - Bracket-mounting engine-electric
control unit
|
XD507389 |
YD522572 |
12,43 |
| 2 |
NNU100910 - Bracket-mounting engine-electric
control unit |
YD522573 |
|
11,95 |
| 3 |
CRC9383 - Pad-insulation
|
|
XD507388 |
0,59 |
| 4 |
GHF1022 - Nut-lokut
|
|
|
|
| 5 |
NNP100810 - Pipe-vacuum engine
- electric control unit
|
|
|
12,00 |
| 6 |
NSC100390 - Sensor-crank engine - Lucas,
long pin |
|
YD522572 |
34,80 |
| 6 |
NSC100760 - Sensor-crank engine - Lucas |
YD522573 |
|
13,49 |
| 7 |
FS105167 - Screw
- M5 x 16
|
|
|
0,35 |
| 8 |
MHK10006 - Sensor-oxygen / lambda sensor
Bosch p/n
0258 003 229 (0258003229)
4-wire
|
|
YD522572 |
145,29 |
| 8 |
MHK100840 - Sensor-oxygen multi point
injection
Bosch p/n
0 258 006 117 (0258006117)
4-wire |
YD522573 |
|
140,11 |
| 8.1 |
weld nut/thread for oxygen sensor,
spare part for exhaust downpipe / catalyst
HJS
90 60 9724-HJS
M18 x 1,5 |
|
|
|
| 9 |
FS105107 - Screw-flanged head
- 10mm, M5 |
|
|
0,34 |
| 10 |
MEK100170
- Transducer coolant temperature
(black for gauge)
superceeded by MEK000030
B.M.W.
1 433 076
13 62 1 433 076
LAND ROVER
MEK000030L
MEK100170L
MEK500130
NSC100870L
ROVER
MEK000030
MEK100170
NSC100870
|
|
|
10,73 |
| 10 |
MEK100060 -
GTR206 GTR313
JAGUAR
LHE 1600AA
ECT Sensor
Transducer coolant temperature - Brown
upper, for ECU input
|
|
YD522572 |
9,79 |
| 11 |
LZN10001 - Insert-screw in |
|
|
0,92 |
| 12 |
JRC3106 - Nut
|
|
|
1,28 |
| 13 |
YCB100370 - Transducer coolant temperature
- Black
GTR270 GTR317 YCB100420
superceeded by
YCB100420 Transducer coolant temperature
1 &
MDY100080 Washer-sealing
|
|
|
9,09 |
| 14 |
MDY100040 - Washer-sealing
|
|
|
0,29 |
| 15 |
NNK10001 - Sensor
IAT-Sensor
-air inlet temperature engine-electric control unit
|
|
|
32,74 |
| 16 |
NSC100320 - Sensor-over temperature
warning catalyst
- Japan - |
|
WD040179 |
60,52 |
| 17 |
ADU7161 - Sensor-carburettor/multi
point injection/tbi coolant temperature
|
|
|
17,47 |
| 18 |
YCB100270 - Transducer oil temperature
- 150 degrees C
|
|
AD001017 |
17,80 |
| 18 |
YCB100290 - Transducer
oil temperature
- 170 degrees C
M10x1
fits to ground plate LPX100360
|
AD001018 |
18K4FJ31 646501
or
18K4FJ32 646201
|
18,61 |
| 18 |
YCB100350 - Transducer
oil temperature
M12x1.5 |
18K4FJ31
646502
or
18K4FJ32
646202 |
XD511058 |
18,87 |
| 18 |
MEK100160A - Transducer oil temperature
superceeded by
MEK000020
|
YD511059 |
|
9,34 |
| 19 |
NUC10003 - Switch
-oil pressure engine
SW24
1/8-27NPT
0.35 Bar
|
|
18K4FJ31 4D646501
or
18K4FJ32 4D646201
|
14,63 |
| 19 |
NUC100280 - Switch
-oil pressure engine
- Brown
|
18K4FJ31 4D646502
or
18K4FJ32 4D646202 |
|
6,37 |
| 20 |
WYC100340 - Clip - Japan
|
|
WD040179 |
0,84 |
| 21 |
YCB100370 - Transducer coolant temperature
- Black
GTR270 GTR317 YCB100420
superceeded by
YCB100420 Transducer coolant temperature
+
MDY100080 Washer-sealing
|
|
|
9,09 |
| 23 |
NSC100930 - Sensor-camshaft engine
superceeded by
NSC100931
NSC100932 |
|
|
30,96 |
| 24 |
FS106127
- Screw-flanged head
- M6 x 12 - cam sensor to cover
|
YD522573 |
|
0,37 |
| 25 |
TGN100050
- O ring
|
|
|
2,42 |
| 26 |
ESR1600A - Clip-cable - 6mm, double
|
1D522573 |
|
0,51 |
| 27 |
MHK100820 - Sensor-multi point injection
manifold pressure
|
|
|
56,66 |
| 28 |
MYP100510 - Screw-duo taptite - M5
map sensor to inlet manifold
2of
|
|
|
0,19 |
| 29 |
YQR101320 - Clip-edge harness
Map Sensor lead to manifold
|
|
|
0,25 |
| 30 |
MHK100520 - Sensor- ambient air engine
bay temperature |
|
app. 3D63? |
14,93 |
| 31 |
MDY100080 - Washer-sealing
Oil pressure switch
|
18K4FJ31 4D646502
or
18K4FJ32 4D646202 |
|
0,67 |
| |
NOT ILLUSTRATED |
|
|
|
| 32 |
UHC000280 - Automatic transmission
control unit
- Except: With Transmission Interlock
superceeded by UHC000320
|
|
4D627834 |
80,29 |
| 32 |
UHC000320 - Automatic transmission
control unit
- Except: With Transmission Interloc
|
4D627835 |
|
80,29 |
| 32 |
UHC000290 - Automatic transmission
control unit
Transmission Interlock -Shift
superceeded by UHC000330
|
|
4D627834 |
84,72 |
| 32 |
UHC000330 - Automatic transmission
control unit
Transmission Interlock -Shift
|
4D627835 |
|
319,59 |
| 33 |
MAU000070 - Bracket-oxygen sensor
|
|
2D600100 |
0,82 |
| 34 |
YYC103970 - Clip OR post cat sensor
-ecu bracket
|
|
YD522573 |
0,47 |
| 34 |
YYC103550 - Clip OR oxygen sensor to
cam cover blank plate
|
|
YD522573 |
1,72 |
